| Usage: |
Used for construction field, low pressure liquid transportation, in various engineering purposes, fencing, scaffolding etc. |
| SAW: |
Submerged arc welded pipe |
| LSAW: |
Longitudinal submerged arc welding pipe |
| SAWL: |
Submerged arc welded longitudinal pipe |
| Standard: |
API 5L, ASTM A500, ASTM A252, ASTM 53, EN10217, DIN 2458, IS 3589, JIS G3452, BS1387 |
| Certificate: |
ISO 9001, ISO 14001, OHSAS 18001, API 5L PSL1&PSL2, CE (CPR & PED), GOST Certificates |
| Out Diameter: |
406.4mm – 1422.4mm (16″-56″) |
| Wall Thk: |
9.53mm-50mm |
| Length: |
6M-12.5M |
| Steel Grade: |
API 5L PSL 1 & PSL2: GR B, X42, X46, X56, X60, X65, X70 ASTM A53: GR.A, GR.B EN10219/EN10210: S275, S275JR, S355JRH, S355J2H GB/T3091: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555 |
| Surface: |
Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement |
| Tests: |
Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (DWT, Guided Bend Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, RT (X-Ray Test) |
| MTC: |
EN 10204/3.1B, EN 10204/3.2 (with Third Party Inspection) |
