Tube for conveyance of fluid

Tube For Conveyance Of Fluid

For conveying oil,gas and other fluid.

Standard	Material Grade
GB/T8163	10#,20#,Q345A,Q345B,Q345C,Q345D,Q345D,Q345E
GB/T5310	20G, 25MnG, 15MoG, 15CrMoG, 12Cr2MoG, 12Cr1MoVG
ASTM A53	GR.A,GR.B
ASTM A106	GR.A,GR.B,GR.C
JIS 3454	STPG 370,STPG 410
JIS 3455	STS 370,STS 410,STS 480

Manufacturing process

Hot rolling process:steel billet → heating → punching → three-roller skew rolling → tube knockout → tube diameter reducing → cooling → semi-finished pipe → straightening→ Hydraulic test →UT→ labeling → warehouse entry.

Cold drawn process: Steel billet → heating → punching → head making → annealing → pickling → copper plating → cold drawing → semi-finished pipes → heat treatment → straightening → water pressure test → labeling → warehouse entry.

OD:33.4mm–508mm (1″o 20″)

WT: 2mm-50mm

Length: Random Length, Fixed Length, SRL,DRL

Surface Treatment: Oil Varnish, black anti-rust paint, hot-dip galvanized,3PE,2PP,2PE,FBE,etc

Packing: Sea package,woven bags, plastic end,in bundled with lifting belts

Ends Design: Beveled ,Plain,Threaded with coupling,Grooved,Square cutted

Special Design available according to customers requirement

Quality Guarantee: SGS,BV,Lloyd’s,DNV,Moody,etc.

Cooperative Partner: Tianjin Pipe Group Corporation(TPCO),Shougang Group, Baosteel Group,Han-Steel Group,Hengyang Valin Steel Tube Co.,Ltd(HYST) and Etc

Project :

Oil and Natural Gas pipeline:Water Conveyance Pipeline,Airport Construction,Railway station Bridge Construction :Power Project and Etc

More details Please see the Project Part.
